Affichage des caractères internationaux dans MapServer

Author:Jeff McKenna
Contact:jmckenna at gatewaygeomatics.com
Last Updated:2016-04-08

Credit

Initial functionality was added to MapServer 4.4.0 as a part of a project sponsored by the Information-technology Promotion Agency (IPA), in Japan. Project members included: Venkatesh Raghavan, Masumoto Shinji, Nonogaki Susumu, Nemoto Tatsuya, Hirai Naoki (Osaka City University, Japan), Mario Basa, Hagiwara Akira, Niwa Makoto, Mori Toru (Orkney Inc., Japan), and Hattori Norihiro (E-Solution Service, Inc., Japan).

Prérequis

  • MapServer >= 4.4.0 (MapServer >= 7.0 for layer-level encoding)
  • MapServer compilé avec la bibliothèque libiconv

How to Enable in Your Mapfile (MapServer >= 7.0)

The MapServer 7.0 release contained changes in how MapServer handles encoding; new in 7.0 is that encoding is set at the LAYER level. This makes it much easier to manage having multiple layers in different encodings, in the same mapfile. The reason for this change was that the encoding of a dataset affects the whole layer, not only the labels. MapServer 7 will also convert any strings into UTF8 in the background, and any output (such as through OGC GetCapabilities, GetFeature, or queries) will be returned in UTF8.

The mapfile LAYER object’s ENCODING parameter accepts the encoding name as its parameter.

MapServer uses GNU’s libiconv library to deal with encodings. The libiconv web site has a list of supported encodings. One can also use the “iconv -l” command on a system with libiconv installed to get the complete list of supported encodings on that specific system.

Note

The label object’s ENCODING parameter is deprecated, but some logic still exists to handle that use in that scenario, in MapServer 7.

Etape 1 : vérifier le support de ICONV et la version de MapServer

Execute ‘’mapserv -v’ at the commandline, and verify that your MapServer version >= 7.0 and it includes ‘’SUPPORTS=ICONV’‘, such as:

> mapserv -v

  MapServer version 7.0.1 (MS4W 3.1.3) OUTPUT=PNG OUTPUT=JPEG
  OUTPUT=KML SUPPORTS=PROJ SUPPORTS=AGG SUPPORTS=FREETYPE SUPPORTS=CAIRO
  SUPPORTS=ICONV SUPPORTS=FRIBIDI SUPPORTS=WMS_SERVER SUPPORTS=WMS_CLIENT
  SUPPORTS=WFS_SERVER SUPPORTS=WFS_CLIENT SUPPORTS=WCS_SERVER
  SUPPORTS=SOS_SERVER SUPPORTS=FASTCGI SUPPORTS=THREADS SUPPORTS=GEOS
  INPUT=JPEG INPUT=POSTGIS INPUT=ORACLESPATIAL INPUT=OGR INPUT=GDAL
  INPUT=SHAPEFILE

Etape 2 : vérifier que vos encodages de fichiers sont supportés par ICONV

Since MapServer uses the libiconv library to handle encodings, you can check the list of supported encodings here: http://www.gnu.org/software/libiconv/

Les utilisateurs Unix peuvent aussi utiliser la commande iconv -l sur un système avec libiconv installé pour obtenir la liste complète des encodages supportés sur ce système en particulier.

Step 3: Add ENCODING Parameter to your LAYER Object

Maintenant, vous pouvez simplement ajouter le paramètre ENCODING dans votre objet de mapfile LAYER, comme ceci :

MAP
 ...
 LAYER
   ...
   ENCODING "SHIFT_JIS"
   CLASS
     ...
   END #class
 END #layer
END #map

Note

Make sure you save your mapfile in the “UTF-8” encoding in your text editor.

LAYER
  NAME "地名"
  DATA "chimei.shp"
  STATUS DEFAULT
  TYPE POINT

  ENCODING "SHIFT_JIS"
  LABELITEM "NAMAE"

  CLASS
    NAME "地名"
    STYLE
      COLOR 10 100 100
    END
    LABEL
      TYPE TRUETYPE
      FONT "pgothic"
      COLOR 220 20 20
      SIZE 7
      POSITION CL
      PARTIALS FALSE
      BUFFER 3
    END
  END
END

How to Enable in Your Mapfile (MapServer < 7.0)

Older MapServer versions only allowed encoding to be set at the LABEL level in the mapfile.

Add ENCODING Parameter to your LABEL Object

Add the ENCODING parameter to your mapfile LABEL object, such as:

MAP
 ...
 LAYER
   ...
   CLASS
     ...
     LABEL
       ...
       ENCODING "SHIFT_JIS"
     END
   END
 END
END

Here is an example layer using the encoding set at the LABEL level:

LAYER
  NAME "chimei"
  DATA "chimei.shp"
  STATUS DEFAULT
  TYPE POINT
  LABELITEM "NAMAE"
  CLASS
    NAME "CHIMEI"
    STYLE
      COLOR 10 100 100
    END
    LABEL
      TYPE TRUETYPE
      FONT "kochi-gothic"
      COLOR 220 20 20
      SIZE 10
      POSITION CL
      PARTIALS FALSE
      BUFFER 0
      ENCODING "SHIFT_JIS"
    END
  END
END

Exemple utilisant PHP MapScript

For PHP Mapscript, the Encoding parameter is included in the LabelObj Class (for MapServer < 7), so that the encoding parameter of a layer can be modified such as:

// Loading the php_mapscript library
dl("php_mapscript.so");

// Loading the map file
$map = ms_newMapObj("example.map");

// get the desired layer
$layer = $map->getLayerByName("chimei");

// get the layer's class object
$class = $layer->getClass(0);

// get the class object's label object
$clabel= $class->label;

// get encoding parameter
$encode_str = $clabel->encoding;
print "Encoding = ".$encode_str."\n";

// set encoding parameter
$clabel->set("encoding","UTF-8");

Remarques

Note

Pendant l’implémentation initiale, cette fonctionnalité a été testée en utilisant les différents encodages systèmes japonais : Shift-JIS, EUC-JP, UTF-8, aussi bien le système d’encodage Thai TIS-620.

Des exemples d’encodage pour l’alphabet latin supportés par libiconv sont : ISO-8859-1 (Alphabet Latin No. 1 - connu aussi sous le nom LATIN-1 - langages de l’Europe de l’Ouest), ISO-8859-2 (Alphabet Latin No. 2 - connu aussi comme LATIN-2 - langages de l’Europe de l’Est), CP1252 (encodage de l’alphabet Latin Microsoft Windows - Anglais et certains langages de l’Europe de l’Ouest).
